LAETSD Time Delay Auxiliary Block 1 NO 1NC For EasyPact TVS

Rp577.157

Main Specification

• Time delay auxiliary product  type
• Signalling device application

Complementary

• EasyPact TVS LC1E range compatibility
• Front mounting location
• On-delay contact auxiliary contacts operation
• 1 NO 1 NC pole contact composition
• 690 V rated insulation voltage – for control circuit conforming to IEC 60947-5-1
• Rated operational voltage <= 690 V
• 8 A (at 60 °C) conventional free air thermal current
• 140 A AC Irms rated making capacity conforming to IEC 60947-5-1
• Rated short-time withstand current
  • 100 A – 1 s
  • 120 A – 500 ms
  • 140 A – 100 ms
• GG fuse 10 A protection type
• 10 cycles mechanical durability
• 5 mA minimum switching current
• 17 V minimum switching voltage
• Non-overlap time:
  • 1.5 ms on energisation no overlap between NC and NO contact
  • 1.5 ms on de-energisation no overlap between NC and NO contact
• 1…30 s time delay range
• Insulation resistance > 10 MOhm

Environment

• Standard environment characteristic
• IEC 60947-5-1 standards
• GOST product certifications
• IP20 conforming to IEC 60529
• TH conforming to IEC 60068 protective treatment
• Ambient air temperature for operation -5…55 °C
• Ambient air temperature for storage -60…80 °C
• 3000 m without derating operating altitude

Out of stock

LAETSD Time Delay Auxiliary Block 1 NO 1NC For Contactor EasyPact TVS Schneider

Schneider LAETSD Time Delay Auxiliary Block

SKU: LAETSD Categories: Contactor, Kontaktor
