Schneider LTMEV40BD 24VDC Extension Module For TeSys T Motor

Rp4.206.900

Main Specification

• TeSys range
• TeSys T product name
• LTME device short name
• Extension module product type
• Equipment monitoring and control device application
• TeSys T LTMR motor controller range compatibility
• Via the controller supply
• Rated insulation voltage 690 V conforming to:
  • EN/IEC 60947-1
  • CSA C22.2 No 14
  • UL 508
• Rated impulse withstand voltage:
  • 6 kV current or voltage measurement circuit conforming to EN/IEC 60947-4-1
  • 0.8 kV supply, inputs and outputs conforming to EN/IEC 60947-4-1
• 4 logic input number
• 7 mA input current
• Logic input: < 5 V and <= 15 mA for 5 ms current state 0 guaranteed
• Logic input: < 15 V and 2…15 mA for 15 ms current state 1 guaranteed
• 2 Hz maximum output switching frequency
• 1800 cyc/h maximum operating rate
• Without contacts type and composition
• Metering type:
  • Voltage U21, U32, U13, V1, V2, V3
  • Imbalance voltage
  • Frequency
  • Calculated active and reactive energy (+/- W.h, +/- VAR.h)
  • Reactive power Q, Q1, Q2, Q3
  • Power factor
  • Active power P, P1, P2, P3

Complementary

• Measurement accuracy:
  • 1 % voltage (100…830 V)
  • 3 % power factor
  • 5 % active and reactive power
• Overvoltage category III
• 5.08 mm connection pitch
• Control circuit: connector 1 cable(s):
  • 0.25…2.5 mm² (AWG 24…AWG 14) flexible with cable end
  • 0.2…2.5 mm² (AWG 24…AWG 14) flexible without cable end
  • 0.25…2.5 mm² (AWG 24…AWG 14) flexible without cable end
  • 0.2…2.5 mm² (AWG 24…AWG 14) solid without cable end
• Control circuit: connector 2 cable(s):
  • 0.2…1 mm² (AWG 24…AWG 14) flexible with cable end
  • 0.2…1.5 mm² (AWG 24…AWG 14) flexible without cable end
  • 0.5…1.5 mm² (AWG 24…AWG 14) flexible without cable end
  • 0.2…1 mm² (AWG 24…AWG 14) solid without cable end
• Control circuit tightening torque 0.5…0.6 N.m flat screwdriver 3 mm
• Electromagnetic compatibility:
  • Electrostatic discharge, 3, 8 kV air, 6 kV contact, conforming to EN/IEC 61000-4-2
  • Fast transients immunity test (other circuits), level 3, 2 kV, conforming to EN/IEC 61000-4-4
  • Fast transients immunity test (on supply and relay outputs), level 4, 4 kV, conforming to EN/IEC 61000-4-4
  • Conducted RF disturbances, 10 V, conforming to EN/IEC 61000-4-6
  • Control circuit: surges (common mode), 1 kV, conforming to EN/IEC 61000-4-5
  • Control circuit: surges (serial mode), 1 kV, conforming to EN/IEC 61000-4-5
  • Communication: surges (common mode), 2 kV, conforming to EN/IEC 61000-4-5
  • Voltage inputs: surges (serial mode), 2 kV, conforming to EN/IEC 61000-4-5
  • Voltage inputs: surges (common mode), 4 kV, conforming to EN/IEC 61000-4-5

Environment

• Standards:
  • IEC 60947-4-1
  • UL 508
  • EN 60947-4-1
  • IACS E10
  • CSA C22.2 No 14
• Product certifications:
  • UL
  • NOM
  • ATEX
  • BV
  • CSA
  • EAC
  • RINA
  • LROS (Lloyds register of shipping)
  • DNV
  • ABS
  • GL
  • KERI
  • RMRoS
  • C-Tick
  • CCC
• IP20 from IP degree of protection
• Protective treatment:
  • 12 x 24 hour cycles conforming to EN/IEC 60068-2-30
  • 48 h conforming to EN/IEC 60070-2-11
  • TH conforming to EN/IEC 60068
• Fire resistance:
  • 650 °C conforming to EN/IEC 60695-2-12
  • 960 °C conforming to UL 94
• -20…60 °C ambient air temperature for operation
• -40…80 °C ambient air temperature for storage
• <= 2000 m without derating operating altitude
• Mechanical robustness:
  • Shocks half sine wave acceleration: 15 Gn for 11 ms conforming to EN/IEC 60068-2-27
  • Vibrations mounted on symmetrical rail: 1 Gn, 5…300 Hz conforming to EN/IEC 60068-2-6
  • Vibrations plate mounted: 4 Gn, 5…300 Hz conforming to EN/IEC 60068-2-6

Out of stock

Schneider LTMEV40BD 24VDC Extension Module For TeSys T Motor

Schneider LTMEV40BD 24VDC Extension Module

SKU: LTMEV40BD Category: Uncategorized
